Engineering Anatomy of Pallet Rack Upright Frames
A pallet rack upright frame consists of two roll-formed upright columns joined by a web of horizontal and diagonal bracing struts bolted or welded in a Pratt or Warren truss geometry. Sourcing structural integrity requires precision control over the profile shape, steel chemical composition, and baseplate anchoring dynamics.
Omega (Ω) Cold-Formed Upright Profiles
Standard upright columns utilize open or modified closed-omega sections. By introducing multiple return bends and stiffening lips along the web and flanges, the second moment of area (Ixx and Iyy) increases significantly. This design elevates the critical Euler buckling limit and prevents premature local torsional-flexural buckling under sustained axial compression loads.
Bracing Truss Configuration
Upright frame depth (typically 800mm to 1200mm) dictates lateral shear strength. HEDA engineers size C-profile horizontal and diagonal bracing members with precision hole-punch spacing. By utilizing high-tensile Grade 8.8 structural locking bolts with nylon-insert lock nuts, joint slippage is suppressed, preserving the vertical frame plane under forklift impact oscillations.
Baseplate Dynamics & Seismic Anchoring
Baseplates distribute concentrated vertical point loads into concrete slab foundations while resisting overturning moment forces. HEDA manufactures baseplates ranging from 4mm to 12mm thickness with CNC dual-hole anchor layouts, accommodating M10 to M16 mechanical wedge or chemical epoxy anchors certified for cracked-concrete seismic zones.
| Steel Grade & Specification | Yield Strength ($R_e$ / $f_y$) | Tensile Strength ($R_m$) | Elongation ($A_5$) | Application Suitability | Equivalency Standard |
|---|---|---|---|---|---|
| Q235B (Standard Hot-Rolled Strip) | ≥ 235 MPa | 370 – 500 MPa | ≥ 26% | Standard ambient pallet racking, light/medium shelving | EN 10025 S235JR / ASTM A36 |
| Q355B (High-Strength Low-Alloy) | ≥ 355 MPa | 470 – 630 MPa | ≥ 22% | High-bay AS/RS racking, seismic zones, heavy cold chain | EN 10025 S355JR / ASTM A572 Gr 50 |
| Q355D / Low-Temp Grade | ≥ 355 MPa | 470 – 630 MPa | ≥ 21% (-20°C Charpy ≥34J) | Blast freezers (-30°C), cryogenic and coastal FMCG depots | EN 10025 S355J2 / ISO 630-2 |
| Galvanized Coil (SGCC / DX51D+Z) | ≥ 280 MPa | 360 – 500 MPa | ≥ 20% | Outdoor stillages, high-humidity, agricultural chemical vaults | ASTM A653 / EN 10346 |
Integrated Racking Manufacturing Excellence Since 2001
Procuring direct from a verified Chinese OEM/ODM tier-1 manufacturer eliminates distributor markups and guarantees complete engineering accountability from preliminary structural layouts to final container packing.
30,000 m² Modern Plant
Equipped with high-precision automated continuous roll-forming lines, automated laser-guided punching presses, and robotic welding clusters capable of 30,000 metric tons monthly output.
Traceable CE & ISO Certification
Audited strictly under CE Certification (No. 2435-CPR-8605159) and ISO 9001:2015 Quality Management (No. 18624Q00169R0M, valid to 2027), ensuring full compliance with European and global safety mandates.
Free 2D CAD & 3D Modeling
Our 300+ technical specialist team provides complimentary floor-plan CAD layouts, 3D photorealistic renderings, and structural deflection calculations tailored to your forklift fleet and floor load rating.
Direct-to-Port Container Packing
Custom steel strapping, edge protectors, and numbered component tagging optimized for rapid sorting at GCC, European, and American terminals, lowering ocean shipping breakage to near zero.
10-Stage Surface Protection Architecture
Every upright frame, shelf beam, and bracing channel manufactured at HEDA undergoes a rigorous multi-stage chemical pretreatment line prior to coating. We do not cut corners with wipe-down cleaning. Our line includes hot alkaline degreasing, twin water cascades, hydrochloric acid pickling for mill-scale removal, zinc phosphating to create an anti-corrosion micro-crystalline layer, and deionized water rinsing.
- Electrostatic powder coating cured at 200°C for 70–90 micron dry film thickness (DFT).
- Cross-hatch adhesion tested to ISO 2409 Class 0 (zero flaking under severe blade scribing).
- 500+ hours neutral salt spray resistance (ASTM B117) without sub-film corrosion creep.
