China Top Warehouse Racking Solutions Exporter & Exporters

We source exclusively from top-tier Chinese state mills (such as Baosteel and Shougang). Every batch of hot-rolled and cold-rolled coil arrives with traceable Mill Test Certificates (MTC) certifying mechanical yield strength (minimum 235 MPa for Q235B and 355 MPa for Q355B). Ultrasonic thickness gauges test steel coil tolerances before slitting.

Yes. Our engineering drawings explicitly incorporate longitudinal and transverse flue spaces (standard 75mm to 150mm gap between back-to-back racks), maintain clear roof-beam clearances for sprinkler throw cones, and provide adequate egress aisle dimensions required by Middle East Civil Defense (UAE, KSA, Qatar) and NFPA 13 codes.

To prepare your tailored layout within 24 hours, provide: (1) Warehouse building DWG or dimensional floor sketch showing column grids and door positions; (2) Clear height to underside of haunch/lighting; (3) Pallet dimensions (W×D×H including cargo overhang) and maximum weight; (4) Forklift model, minimum turning aisle, and max mast lift height.

Before powder application, our steel components pass through a 9-stage pre-treatment line featuring hot alkaline degreasing, twin acid pickling rinse, and zirconium phosphating. We electrostatically spray lead-free thermosetting polyester powder at 60–80 microns thickness, cured at 200°C for exceptional bond strength, scratch resilience, and salt-spray defense.

Our 30,000 m² factory with a 30,000-ton monthly capacity ensures standard pallet racking orders of 1 to 5 containers ship in 15 to 20 days post drawing sign-off. Larger custom mezzanine systems or automated shuttle projects typically require 25 to 30 days including pre-assembly trial alignments.

We handle direct factory-to-port ocean shipments via FOB, CIF, or DDP. Routine export destinations include Jebel Ali and Khalifa Port (UAE), Dammam and Jeddah (Saudi Arabia), Hamad Port (Qatar), Sohar (Oman), Shuwaikh (Kuwait), Singapore, Rotterdam, Felixstowe, Durban, Houston, and Santos.

Yes. Our teardrop upright punch configuration strictly adheres to RMI ANSI MH16.1 standards, utilizing a 2-inch pitch. This ensures 100% interoperability with major North American teardrop profiles, allowing seamless replacement or expansion of existing installations without replacing upright frames.

Every structural installation can be equipped with heavy-gauge U-shaped and L-shaped upright post protectors, wrap-around column guards, heavy frame end barriers, pallet back-stops, steel or wire-mesh decking panels with drop-over waterfall lips, and beam spring-lock safety pins.

Uprights and beams are bundled using high-tensile steel strapping over corrugated edge protectors, then encased in anti-moisture thermal shrink wrap. Direct wood dunnage spacers prevent metal-on-metal abrasion, and desiccant packs inside the shipping containers prevent condensation corrosion.

Yes. Our senior structural engineers deliver comprehensive finite-element calculation packages covering dead loads, live pallet loads, seismic ground acceleration coefficients (Ss and S1), and baseplate anchor pull-out shear forces, ready for submission to municipal civil building authorities.
