To provide an accurate structural drawing and BOM (Bill of Materials), our engineering department requires: (1) Warehouse architectural drawings in CAD format showing building clear height (underside of rafters or sprinkler heads), column grid spacing, floor slab expansion joints, and loading dock positions; (2) Pallet specifications including width, depth, overall overhang, maximum load height, and gross pallet weight; (3) Material handling equipment (MHE) specifications including forklift make/model, mast collapse height, maximum fork elevation, and turning radius (Ast); (4) Throughput requirements, whether the inventory model operates on FIFO (First-In, First-Out) or LIFO (Last-In, First-Out). Our engineers return a complete 2D layout and 3D rendering within 24 to 48 hours.

Our storage solutions are designed in strict alignment with NFPA 13 (Standard for the Installation of Sprinkler Systems) and local Civil Defense authorities (including UAE Civil Defense, Saudi Civil Defense, and European fire safety mandates). Our engineering layouts maintain standardized longitudinal flue spaces (typically 150mm between back-to-back racks) and transverse flue spaces (minimum 75mm to 100mm between pallet loads) to ensure unimpeded vertical thermal updraft and sprinkler penetration. Wire mesh decking panels with open area >50% can be supplied to facilitate downward water penetration.

Guangzhou Heda Shelves Co., Ltd. operates under accredited quality systems: CE Certification (No. 2435-CPR-8605159) in compliance with European structural steel standards EN 15512 and EN 1090; ISO 9001:2015 Quality Management Certification (No. 18624Q00169R0M), and RoHS Compliance on all applied surface pre-treatments and powder coatings. Complete Mill Test Certificates (MTC 3.1) and third-party finite element structural reports are provided with commercial documentation.

Environmental endurance is rooted in chemical pre-treatment. Components undergo continuous 9-stage immersion: alkaline degreasing, clean water rinse, hydrochloric acid pickling (to remove all hot-rolled mill scale), surface phosphating conversion, and passivating rinses. Automated electrostatic powder coaters then deposit thermosetting architectural-grade polyester resin at 60-90 microns, cured at 200°C. For aggressive coastal or outdoor open-air staging yards, we offer Hot-Dip Galvanizing (HDG) to ASTM A123 / ISO 1461, providing zinc coatings >65-80 microns for decades of maintenance-free service.

Standard production turnaround for 2 to 5 full container loads (FCL 40HQ) is 15 to 22 business days from final drawing sign-off. Upright frames are either shipped fully pre-assembled or knock-down flat-packed (saving up to 40% ocean freight volume). Beams are packaged in steel-strapped bundles with corrugated paper corner protectors and nylon sling points. Fasteners, baseplates, shims, safety pins, and small accessories are packed in sealed, export-grade plywood crates indexed to CAD erection drawings.

Yes. As a direct OEM factory, we design custom roll-forming tooling dies for established international racking brands and regional distributors. We manufacture proprietary upright slot styles (Teardrop, Hexagonal, Diamond, or Keyhole patterns), bespoke connector brackets, custom RAL powder finishes, and private-label silk-screened or stamped load placards with client branding.
