Direct factory production line supplying certified upright frames, heavy-duty shelving, blow-molded Euro pallets, and dynamic material handling systems with full traceability under European CPR standards.
Anti-corrosion welded structural steel frame specifically suited for Italian prosciutto maturation cellars, cheese curing rooms, and pharmaceutical facilities.
High-strength Q355B structural steel warehouse upright system designed for machine tool storage, automotive parts depots, and manufacturing buffer zones.
One-piece 1210*1200*150mm heavy-duty blow molding pallet engineered for high-bay racking beam levels with anti-skid rubber plugs and steel reinforcement pipes.
Multi-tier modular picking cart equipped with industrial ESD wheels and chrome wire decks, optimized for fast-moving Italian fashion and third-party logistics.
Impact-resistant polypropylene front-opening bins integrated into pallet rack lower picking tunnels for hardware, fittings, and automotive assembly lines.
Cold-roll formed Omega profile uprights and stepped box beams accommodating up to 4,500 kg per level, calibrated to UNI EN 15512 safety deflection limits.
Vertical volumetric expansion systems combining heavy upright columns with integrated perforated steel grating decking, walkways, and safety handrails.
Continuous single-piece upright columns up to 14 meters in length, pre-punched for drop-pin connectors, diagonal seismic bracing, and guide rail integration.
An authoritative engineering breakdown of cold-formed Omega profiles, yield strength criteria, perforation geometries, and load-bearing parameters under European standard UNI EN 15512:2020.
Our upright frames utilize a proprietary multi-bend Omega cross-section produced via an automated 22-station continuous cold roll-forming line. The integrated 8 to 12 lateral stiffening ribs prevent torsional buckling and local elastic deformation under high concentrated point loads.
Sourced exclusively from certified Tier-1 steel mills (Baosteel/Shougang), every master coil is chemically analyzed and tensile-tested to guarantee mechanical parity with European steel designation S355JR / S275JR under EN 10025-2 standards.
Before powder deposition, upright components undergo an automated 7-stage immersion process: hot degreasing, dual rinsing, deoxidizing acid pickling, zinc phosphating, and demineralized seal. Finished with thermo-hardened epoxy-polyester powder coating.
| Upright Model Code | Profile Dimensions (W x D) | Material Thickness | Sectional Area (cm²) | Max Frame Capacity (kg)* | Primary Industrial Application in Italy |
|---|---|---|---|---|---|
| HEDA-UP-80L | 80 mm x 68 mm | 1.8 mm | 3.24 cm² | 8,500 kg | Light manual picking, retail stockrooms, multi-tier mezzanines |
| HEDA-UP-90M | 90 mm x 70 mm | 2.0 mm | 4.12 cm² | 14,000 kg | Standard Euro-pallet storage (1200x800), regional 3PL fulfillment |
| HEDA-UP-100H | 100 mm x 70 mm | 2.5 mm | 5.48 cm² | 21,000 kg | Food & Beverage, cold stores (-25°C), seismic Zone 3/4 facilities |
| HEDA-UP-120XH | 120 mm x 95 mm | 2.5 mm / 3.0 mm | 7.65 cm² | 28,500 kg | High-bay VNA installations, drive-in racking, industrial tooling |
| HEDA-UP-140HD | 140 mm x 105 mm | 3.0 mm | 9.82 cm² | 35,000 kg | Automated AS/RS integration, heavy die manufacturing, Zone 1 seismic |
*Note: Maximum frame capacity varies based on unbraced length (first beam elevation height), seismic coefficient ag/g, and structural floor anchoring condition. Complete engineering static calculations per UNI EN 15512 are provided with every order.
Italy possesses some of the strictest seismic building codes in Europe. Learn how our custom OEM pallet rack uprights are calculated to mitigate ground acceleration dynamics in high-risk zones.
Under Italian Ministerial Decree 17/01/2018 (Aggiornamento delle Norme Tecniche per le Costruzioni - NTC 2018), storage racks are classified as structural steel systems. We engineer upright assemblies specifically tailored to site-specific peak ground acceleration ($a_g$) values ranging from 0.05g up to >0.25g.
Our structural engineering department conducts modal response spectrum analysis and global second-order (P-Delta) sway calculations. Upright bracing configurations utilize cold-formed C-profiles (30x20mm to 40x25mm) forming rigid K-trusses or D-trusses that dissipate kinetic energy without joint rupture.
The interface between the upright column and the industrial concrete slab is critical in Italian seismic events. We provide CNC-punched, robotic welded heavy-gauge baseplates (thickness 6mm to 12mm) featuring dual-offset anchor holes to prevent localized edge spalling in cracked concrete slabs.
From high-throughput intermodal freight villages (Interporti) to temperature-controlled agricultural food corridors, our custom OEM uprights power key sectors of the Italian economy.
Italy’s Quadronte Europa in Verona and Interporto di Bologna demand maximum floor space utilization and continuous cycle reliability. Our 100mm and 120mm uprights support 12-meter clear heights, narrow aisles (VNA), and heavy pallet turnover rates of up to 2,500 pallet cycles per shift.
In the Po Valley food cluster, storing Parmigiano Reggiano wheels, cured ham, and boxed prosecco requires structural stability under high point-loads and controlled humidity. We deliver hot-dip galvanized or epoxy-polyester treated frames that withstand condensation and washdown cycles.
Supporting the "Motor Valley" and Piedmont manufacturing clusters, our heavy 120mm/140mm uprights (3.0mm thickness) carry heavy stamping dies, engine castings, and transmission crates up to 4,000 kg per pallet level without structural deflection.
Textile and luxury goods distribution centers require multi-tier picking towers built on rack-supported mezzanine frames. Our precision uprights integrate multi-level mezzanine walkways, overhead lighting channels, and automated garment-on-hanger (GOH) rails.
Strategic dynamics transforming warehouse procurement in Italy, including governmental tax incentives, land constraints, and automated logistics integration.
Under Italy’s National Recovery and Resilience Plan (PNRR) and the Piano Transizione 5.0 framework, warehouse investments that cut energy usage qualify for tax credits. Upright designs must now accommodate high-density radio shuttle carts, automated automated guided vehicles (AGVs), and stacker cranes, requiring strict upright manufacturing tolerances within ±1.0 mm per 10 meters.
Due to environmental zoning constraints in Lombardia and Emilia-Romagna, logistics operators cannot expand outward. The trend is maximizing vertical airspace (from standard 8m up to 14m clear height inside existing footprints). This shifts demand toward heavy-section 120mm/140mm uprights capable of bearing higher total combined bay loadings (up to 30 tons).
Italian institutional investors and international REITs (such as Prologis, GLP, and Segro) demand rigorous Environmental Product Declarations (EPD) for all warehouse building elements. Our upright production utilizes low-emission electric induction roll-forming, zero-VOC electrostatic powder, and scrap recycling efficiencies exceeding 98%.
In-depth technical answers addressing customs clearance at Genoa/Trieste, seismic calculation documentation, compatibility with European profiles, and OEM branding options.
Yes. All pallet racking upright columns, frame bracings, and beam connectors fabricated by Guangzhou Heda Shelves Co., Ltd. are engineered in full conformity with EN 15512:2020 (Steel static storage systems - Adjustable pallet racking systems - Principles for structural design) and UNI EN 16681 (Anti-seismic design of pallet racking). We hold European CE certification (No. 2435-CPR-8605159) under the Construction Products Regulation (CPR 305/2011/EU) and ISO 9001:2015 quality management certification. With every commercial shipment, we provide full factory Declaration of Performance (DoP), Mill Test Certificates (EN 10204 Type 3.1), and complete static calculation reports for submission to Italian municipal authorities (Genio Civile).
Absolutely. Over 65% of our export output is OEM contract manufacturing. We have dedicated tooling libraries for both 50.0mm European modular pitch and 75.0mm standard pitch, as well as teardrop or proprietary slotted hole patterns. If you are an Italian racking brand, distributor, or system integrator looking to outsource upright column roll-forming, we can customize profile roll tooling, hole punches, frame bracing bolt holes, and company logo stamps to ensure 100% mechanical compatibility with your existing beam connector lugs and baseplates.
We export directly from our Guangzhou facility via Nansha or Yantian ports directly to major Italian maritime ports: Port of Genoa (Genova Pra'), Port of La Spezia, Port of Livorno, Port of Naples (Napoli), and Port of Trieste. Average ocean transit time is between 28 to 35 days. Upright frames are shipped disassembled (knocked-down) to maximize container volume (up to 24–26 metric tons per 40ft High Cube container) with color-coded bundle labeling that directly matches the erection drawings. We provide full export documentation including EUR.1 / Certificate of Origin, Bill of Lading, Commercial Invoice with correct HS/Taric Classification Codes (typically HS 7308.90 for structural steel racking components), and Packing Lists to guarantee rapid clearance through Italian Dogane.
For standard dry ambient warehouses, our automated pre-treatment immersion (acid pickling and zinc phosphating) followed by thermosetting electrostatic polyester powder coating (60–90 μm thickness) ensures superior scratch and moisture resistance, available in any RAL color (standard RAL 5010 Blue, RAL 2004 Orange, or custom corporate palettes). For cold storage facilities (-25°C blast freezers in the agricultural sector) or coastal logistics zones in Liguria and Campania with saline air, we offer continuous pre-galvanized coils (Z275 coating) or batch Hot-Dip Galvanizing (HDG per UNI EN ISO 1461) with zinc coating thickness exceeding 70–85 μm for complete multi-decade rust immunity.
Yes. Our in-house technical engineering department employs over 30 structural engineers. When you supply your architectural floor CAD drawing, ceiling clear heights, slab specifications, forklift parameters (turn radius and mast elevation), and pallet load characteristics, we generate a comprehensive 2D DWG layout plan, 3D photorealistic renderings, and FEA static structural reports free of charge prior to manufacturing. This documentation clearly identifies aisle clearances, flue spaces for fire safety, beam deflection ratios ($L/200$ or $L/300$), and anchor pull-out forces.
Combining over two decades of heavy industrial fabrication expertise with high-volume precision roll-forming technology.
Founded in 2001, Guangzhou Heda Shelves Co., Ltd. operates an expansive 30,000 square meter modern manufacturing footprint in Guangzhou. Every stage of upright column production—slitting, continuous cold roll-forming, automatic stamping, robotic welding, and powder coating—is executed entirely in-house without subcontracting.
With 18 automated roll-forming lines, 10 high-speed punch presses, 12 robotic welding cells, and 2 full-length automatic electrostatic powder coating lines, our factory reliably processes 30,000 metric tons of raw steel per month, ensuring swift delivery schedules for large commercial distribution centers.
From spectral raw material analysis on incoming steel coils to ultrasonic weld inspection and powder coating thickness tests (ISO 2808), our internal QC department ensures zero tolerance for structural defects. Each batch is traceable back to its specific production line, operator, and raw coil mill heat number.
Having served clients in over 120 countries, our export engineering department understands European logistics standards, container packing optimizations to minimize sea freight costs, and multilingual technical documentation to support local Italian assembly teams.
Share your facility dimensions, pallet specifications, or custom upright drawings. Our engineering team will deliver a comprehensive 2D CAD floor plan, 3D render, and competitive factory-direct export quote within 24 business hours.
